This product is a 12864 LCD dot matrix display capable of displaying graphics at a resolution of 128 columns × 64 rows of pixels. The display uses an FSTN mode LCD with an LED backlight, featuring a gray background with blue-black characters, high contrast, and a wide viewing angle. The module includes a built-in driver chip and is manufactured using COG (Chip-on-Glass) technology, resulting in a thin and lightweight product with ultra-low power consumption and a wide operating temperature range. It connects to the host MCU via an SPI interface and is used to display various images and text.
This product is a 12864 LCD dot matrix display capable of displaying graphics at a resolution of 128 columns × 64 rows of pixels. The display uses an FSTN mode LCD with an LED backlight, featuring a gray background with blue-black characters, high contrast, and a wide viewing angle. The module includes a built-in driver chip and is manufactured using COG (Chip-on-Glass) technology, resulting in a thin and lightweight product with ultra-low power consumption and a wide operating temperature range. It connects to the host MCU via an SPI interface and is used to display various images and text.
This type of graphic dot matrix display is available in various resolutions, including 122×32, 128×64, 128×128, 144×32, 160×160, 160×32, 160×80, 192×64, 240×64, 240×128, and 320×240. Customers can choose different combinations of LCD backlight and LCD panel types according to their product requirements, and custom options are also available.
| Manufacturer | Eastern?Display |
| Product model | EDM12864-159 |
| Display content | 128x64 dot matrix display |
| Background | Gray |
| Interface | SPI interface |
| Driver chip model | LCD?controller??IST7920 |
| Module type | COG?LCD?Module |
| Connection | PIN |
| Display type | FSTN LCD，Positive，Transflective |
| Viewing angle | 6 O'clock |
| Operating voltage | 3.3V |
| Backlight type | LED?backlit |
| Backlight color | White |
| Operating temperature | -30~70℃ |
| Storage temperature | -40~80℃ |
Keywords：LCD display screen/LCD16x2/LCD display 16x2/i2c LCDdisplay/ips LCD/led backlit LCD/Dot matrix display/LCD dot matrix display/mini LCD screen/transparent LCD screen/LCD1602/r LCD/EDC18109-01/EDC9697VA/EDC9698VA?
